Veltok Power
1 / 5
| Input Voltage Range: 100--240V/AC (96~264V/ac) |
| Input Frequency: 50-60Hz |
| Output Range: 3V~48V DC, 0.3A~100A (Customized spec available) |
| Output Power: 3W~2000W |
| Output Ripple: 100-150mV-P |
| Over Voltage Protection: 130% min |
| Over Current Protection: 150% min |
| Protection Functions: Short circuit, overload, overvoltage protection |
| Output Voltage Accuracy: ± 5% |
| Working Temp: 0-40 °C |
| Storage Temp: -20-85 °C |
| Working Humidity: 5-95% RH |
| Insulation: AC 3000V (MIN), 5mA (Max) |
| Insulation Resistance: DC 500V 100M (Min) |
| Aging Test: Full load aging of 4 hours or more |
| Pull Test: Fixed at one end, 20 nm at other end for 5 seconds without damage |
| Safety Certificates: CE / FCC / UL / SAA / GS / UKCA |
| Applications: Security systems, instrumentation, medical equipment, audio-visual, LED lighting, electric cars |
| After Sale Service: 24 months warranty |
