Veltok Power
1 / 5
| ✔ Input voltage range: 100--240V/AC (96~264V/ac) |
| ✔ Input frequency: 50-60Hz |
| ✔ Output: 3V~48V DC, 0.3A~100A (Customized spec available) |
| ✔ Output power: 3W~2000W |
| ✔ Output ripple: 100-150mV-P |
| ✔ Over voltage protection: 130%min |
| ✔ Over current protection: 150%min |
| ✔ Protection function: short circuit, overload, overvoltage protection |
| ✔ Output voltage accuracy: + 5% |
| ✔ Working environment temperature: 0-40 °C |
| ✔ Storage temperature: -20-85 °C |
| ✔ Working humidity: 5-95%RH |
| ✔ Insulation: AC3000V(MIN), 5mA(Max) |
| ✔ Insulation resistance: DC 500V 100M (Min) |
| ✔ Aging test: full load aging of 4 hours or more |
| ✔ Safety certificate: CE/FCC/UL/SAA/GS/UKCA |
| ✔ Application: security systems, medical equipment, audio-visual products, LED lighting |
| ✔ Warranty: 24 months |
